2-42
2-4 External and Mounting Dimensions
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
3-phase 400 VAC: R88D-KT150F (15 kW)
Wall Mounting
External dimensions
Mounting dimensions
261
231
30.5
450
7.5435
30.5
231
4
270
R3.5 R3.5
φ7φ7
70
261
450
435
200
30.5
4-M6
