7.04.03 Function keys
The functions keys described below are used essentially to switch machine functions on and
off. When the function is switched on, the diode in the key is illuminated.
If a corresponding value has to be fixed for the activated function, this can be carried out
with the corresponding +/- keys 3.
By pressing and holding the corresponding +/- key, firstly the numerical value displayed abo-
ve it is altered slowly. If the +/- key is pressed longer, the numerical value changes more
quickly. The respective +/- keys shown opposite are described below.
input. If the input required is invalid, e.g. because the max. permissible value for the
parameter input has been reached, a double tone is audible. An SD-card reader for data
transfer is integrated.
7.04.01 Screen displays
Depending on the operating mode, on the screen 1 information is shown about the machine
status, program selection, sequence program progress, input parameters, as well as error si-
gnals (also see Chapter 11 Input).
Depending on the operating mode, relevant data is displayed in combination with the ap-
propriate symbol or text, and can be altered directly.
When the parameters are entered, the number of the parameter selected is shown with
the corresponding parameter value, see Chapter 11.03 Parameter input.
If faults occur in the sewing operation, a corresponding error signal appears in the display,
see Chapter 11.08 Error messages on the display.
●
●
●
7.04.02 Display symbols
Program number
Speed
X Size factor X-direction (crosswise) in %
Y Size factor Y-direction (lengthwise) in %
Bobbin thread counter / piece counter
Enter
Machine memory
SD-memory card
To Next Page
