Setting up
27
Fig. 9 - 03
6
9.03 Winding the bobbin thread
Place the empty bobbin 1 on the bobbin winder spindle 2.
Thread the thread as shown in Fig. 9-03 and wind it round bobbin 1 a few times in the
anti- clockwise direction.
Set the preliminary thread tension by turning milled screw 3.
Press lever 4 in the direction of the arrow until it clicks into place.
The bobbin is filled during sewing.
Winding is also possible as follows:
Switch on the machine and press the key for winding.
Remove the thread from the needle and take-up lever.
Operate the pedal to carry out winding, the bobbin winder stops automatically as soon as
the bobbin is adequately full.
Press the key for winding, the machine stops.
Thread the machine again.
Adjusting the amount of thread on the bobbin
Loosen screw 5.
Set stop 6 so that the bobbin winder switches off automatically when the thread is
still ca. 1 mm from the edge of the bobbin.
Tighten screw 5.
●
●
●
●
●
●
●
●
●
●
●
●
●
2
1
5
4
3
