Installation and commissioning
19
Loosen screws 1 and 2 and set the table height as required.
Firmly tighten screw 1.
Set the required pedal position and tighten screw 2.
●
●
●
8 Installation and commissioning
The machine must only be installed and commissioned by qualified personnel!
All relevant safety regulations must be strictly adhered to!
If the machine is delivered without a table, be sure to use a stand and table top
that can hold the weight of the machine with its motor.
It is very important to ensure that the stand of the machine is firm and steady,
also during sewing.
8.01 Installation
The site where the machine is installed must be provided with suitable connections for the
electric current, see Chapter 3 Specifications.
It must also be ensured that the standing surface of the machine site is firm and horizontal,
and that sufficient lighting is provided.
For packing and transportation reasons the table top is in the lowered position.
The table height is adjusted as described below.
If the machine is delivered with stand, the transit lock must be removed before
commissioning, see Chapter 8.01.02 Removing the transit lock.
8.01.01 Adjusting the table height
Fig. 8 - 01
2
1
1
