Page #37 background image
37Benutzerhandbuch
DEUTSCH
Rückmeldung (Piepton), wenn der Batterie-
ladestand unter 10% fällt oder der verfügbare
Speicher unter 2 Minuten fällt.
Um eine Indexmarkierung einzufügen, •
drücken Sie während der Aufnahme oder
Wiedergabe den Smart-Button
INDEX.
Weitere Informationen finden Sie unter
Indexmarkierungen verwenden auf Seite 45.
Halten Sie den Smart-Button •
ANWEISG hrend
der Aufnahme gedrückt, um eine gesprochene
Anweisung aufzunehmen. Weitere Informatio-
nen dazu finden Sie im nächsten Kapitel.
Aufnehmen gesprochener 4.1.2
Anweisungen
Gesprochene Anweisungen sind vom Autor wäh-
rend des Diktats aufgenommene Kommentare für
die Person, die das Diktat transkribiert Sogen
Sie eine gesprochene Anweisung in das Diktat ein:
Halten Sie den Smart-Button 1
ANWEISG
während der Aufnahme gedrückt.
Diktieren Sie die Anweisungen.2
Lassen Sie den Smart-Button 3
ANWEISG
1
los,
wenn Sie mit den gesprochenen Anweisun-
gen fertig sind. Die Anweisung wird als dicke
Linie auf der Positionsleiste angezeigt
a
.
DPM 9600
INDEX INSTR
9:23
#2
1
a
Ergänzungen in ein Diktat einfügen4.1.3
Gemäß Voreinstellung werden die Diktate im
Überschreibmodus aufgezeichnet. Gehen Sie wie
folgt vor, um zum Einfügemodus zu wechseln
und Ergänzungen zu Ihrem Diktat aufzunehmen:
Drücken Sie im Stoppmodus die 1
FUNKTIONS-
Taste
1
, um zwischen den Modi Einfügen
und Überschreiben zu wechseln. Im Einfüge-
modus wird das Symbol
a
angezeigt.
Im • Einfügemodus trägt die Aufnahme-
position des Schiebeschalters die
Aufschrift
eAUFN und die Status-LED
2
leuchtet während der Aufnahme grün.
Im • Überschreibmodus trägt die Aufnahme-
position des Schiebeschalters die
Aufschrift
AUFN und die Status-LED
2
leuchtet während der Aufnahme rot.
Drücken Sie die Taste 2 + oder
3
, um
die Datei, in die Sie Ergänzungen einfügen
möchten, auszuwählen.
Steuern Sie durch Wiedergabe, Vorlauf 3
bzw. Rücklauf die Position an, an der Sie
Korrekturen vornehmen möchten.
DPM 9600
KEYWORD NEW
5:12
#2
a
3
1
2
Nehmen Sie Ergänzungen im Diktat vor:4
Auf dem • Digital Pocket Memo 9600

Table of Contents

Other manuals for Philips LFH 9600

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips LFH 9600 and is the answer not in the manual?

Philips LFH 9600 Specifications

Connectivity IconConnectivity
docking connector8-pin female
USBMini USB 2.0 female (full speed, 12 Mbit/s)
DC in voltage6 V
microphone impedance2 kΩ
earphone impedance8 Ω or more
Display IconDisplay
display typeTFT-Transreflective
diagonal screen size1.71 " / 44 mm
resolution128 × 128 pixels
Power IconPower
power supply6V DC / 850 mA
power consumption800 mA maximum
battery typetwo Philips AAA Ni-MH rechargeable batteries (LFH 9154) or two AAA batteries (LR03 or R03)
battery life with Philips Ni-MH rechargeable battery17 hours
battery life with Philips alkaline battery15 hours
charging time (USB fast charging)2.5 hours
Recording Specifications IconRecording Specifications
recording formatDSS / DSS Pro (Digital Speech Standard)
memory typeSecure Digital (SD)/ Multimedia Card (MMC) up to 2 GB
recording modesQuality Play (QP), Standard Play (SP), Long Play mobile (LPm)
recording time with 128 MB card10.7 / 21.8 / 32.7 hours
recording time with 2 GB card170 / 349 / 523 hours
sampling frequency (Quality Play mode)16 kHz
sampling frequency (Standard Play mode)12 kHz
sampling frequency (Long Play mode)8 kHz
compression rate (Quality Play mode)26 kbit/s
compression rate (Standard Play mode)13.5 kbit/s
compression rate (Long Play mode)9 kbit/s
frequency response (Quality Play mode)200 to 7 500 Hz
frequency response (Standard Play mode)200 to 5 500 Hz
frequency response (Long Play mode)200 to 3 500 Hz
Speaker IconSpeaker
built-in speaker30 mm round dynamic speaker
output power200 mW
Operating Environment IconOperating Environment
operating temperature5° - 45° Celsius / 41° - 113° Fahrenheit
humidity10 % - 90 %
Weight and Dimensions IconWeight and Dimensions
product dimensions (W x D x H)50 x 116 x 17 mm / 2.0 x 4.6 x 0.7 inch
weight106 g / 3.7 oz, including two Philips AAA Ni-MH rechargeable batteries (LFH 9154)
