<40 A
YES go to 10 NO go to 11
7- Low trailing speed
High electrical absorption
Carry out a test of the engine rotation (example: possible melting of the bushes) and if no anomalies
are found, replace the starter motor.
8- Low trailing speed
Low electrical absorption
Repeat the test, bridging the power terminals of the starter remote control switch or even better replacing
them.
Check the new values.
YES go to 12 NO go to 13
9 - High trailing speed
Low electrical absorption
The engine turns too freely, check the compression end pressure.
If the values are not correct proceed as follows.
10 - The starter motor works properly.
11 - Check the rotation of the armature.
12 - Replace the starter remote control switch.
13 - Test the battery again and if necessary replace the starter motor.
N.B.
IF THE TRAILING SPEED OF THE CRANKSHAFT IS LOW AND COMBINED WITH STRANGE
NOISE, CHECK THE FREEWHEEL OF THE TORQUE LIMITER (SEE THE "FLYWHEEL AND
STARTER SYSTEM" CHAPTER).
STARTER MOTOR
Specification
Desc./Quantity
Type Mitsuba sm13d
Power 0.9 kW
BATTERY
Specification
Desc./Quantity
Capacity 14 Ah
Starting current 125 A
START-UP REMOTE CONTROL SWITCH
Specification
Desc./Quantity
Type SEALED
Maximum load 150 A continuous
STARTER TRANSMISSION
Specification
Desc./Quantity
Ring gear and freewheel coaxial to the flywheel. Intermediate gear with built-in torque limiter.
The starter system has a transmission between the motor armature and engine shaft equipped with
freewheel coaxial to the flywheel and torque limiter on the intermediate shaft.
Engine X9 Evolution 500
ENG - 128
