Assemble the Seeger ring.
•
Assemble the oil seal flush with the in-
ternal surface as shown in the figure to
the hub using the adequate tools and
with the seal lip towards the inside of
the hub.
Specific tooling
020376Y Adaptor handle
020360Y Adaptor 52 x 55 mm
Refitting the hub cover bearings
- For the fitting of the hub box bearings the engine crankcase and the cover must be heated with the
specific heat gun.
Specific tooling
020150Y Air heater support
020151Y Air heater
- The three 15 mm bearings must be fitted using
the appropriate tools.
Refitting the hub bearings
- Insert the cover prepared in the crankcase taking
care of inserting the gear of the pulley shaft on the
intermediary gear.
Fly 125 - 150 4T Engine
ENG - 101
