Sospensioni anteriore
This section is devoted to operations that can be carried out on the suspension.
Front
Removing the front wheel
- Remove the wheel axle locking nut.
- Remove the wheel axle and the wheel.
- Upon removal take care not to damage the sen-
sor that detects movement in the odometer.
Front wheel hub overhaul
Cuscinetti a sfere sul mozzo ruota
- Remove the front wheel
- Keep the wheel level by means of two wooden
wedges
- With the appropriate pliers and tool remove the
wheel bearing on the side the rpm indicator detects
movement, as shown in the photograph
- Remove the internal spacer
- Use appropriate handle, adaptor and guide and
hit with a mallet to extract the bearing and the
spacer bushing on the brake disk side; insert han-
dle on the side the rpm indicator detects move-
ment, as shown in the photo
Suspensions Fly 125 - 150 4T
SUSP - 158
