PIAGGIO Fly 150 4T User Manual

CONTACT AN AUTHORISED PIAGGIO SERV-
ICE CENTRE TO CARRY OUT THESE OPERA-
TIONS.
Carburettor
125cc Version
Kehin
CARBURETTOR SETTING
Specification Desc./Quantity
Type CVEK26
Throttle valve diameter Ø 26.5
Diffuser diameter Ø 26.4
Setting stamping 262A
Maximum jet 82
Maximum air jet (on the body) 85
Tapered pin stamping NELA
Throttle valve spring 130 ÷ 180 gr.
Minimum jet 35
Idle air jet (on the body) 150
Idle mixture adjustment screw initial opening 1 ¾
Starter jet 42
Starter air jet (on the body) Ø 1.5
Starter pin travel 10 mm (at 24°)
Starter resistance 20 Ohm (at 24°)
150cc Version
Kehin
CARBURETTOR SETTING
Specification Desc./Quantity
Type CVEK26
Throttle valve diameter Ø 26.5
Diffuser diameter Ø 26.4
Setting stamping 265A
Maximum jet 82
Maximum air jet (on the body) 85
Tapered pin stamping NELA
Throttle valve spring 130 ÷ 180 gr.
Minimum jet 35
Idle air jet (on the body) 150
Idle mixture adjustment screw initial opening 1 ¾
Starter jet 42
Starter air jet (on the body) Ø 1.5
Starter pin travel 10 mm (at 24°)
Characteristics Fly 125 - 150 4T
CHAR - 12
