Helmet bay
- Remove the side fairings
- Remove the helmet compartment by undoing the
4 screws indicated in the figure
Fuel tank
- Remove the side fairings
- Remove the rear mudguard
- Remove the crews shown in the photograph
- Remove the shock absorber upper clamping in
order to create the necessary space to take out the
tank.
Fly 125 - 150 4T Chassis
CHAS - 177
