SAS filters inspection and cleaning
- Remove the shock absorber lower retainer from
the engine.
- Remove the retainer clamp indicated in the pho-
tograph, the automatic starter cable harness and
the carburettor to frame heater placed under the
helmet compartment cover.
- Lift the vehicle with a jack as shown in the figure
to be able to reach the flywheel cover screws
- Remove the screw fixing the SAS valve to the
flywheel cover, indicated in the photograph.
Maintenance Fly 125 - 150 4T
MAIN - 42
