Piston rings
SEALING RINGS (125)
Name Description Dimensions Initials Quantity
Compression ring 57 x 1 A 0.15 ÷ 0.30
Oil scraper ring 57x1 A 0.10 ÷ 0.30
Oil scraper ring 57x2.5 A 0.10 ÷ 0.35
Compression ring
1st oversize
57.2 x 1 A 0.15 ÷ 0.30
Oil scraper ring 1st
oversize
57.2x1 A 0.10 ÷ 0.30
Oil scraper ring 1st
oversize
57.2x2.5 A 0.10 ÷ 0.35
Compression ring
2nd oversize
57.4x1 A 0.15 ÷ 0.30
Oil scraper ring
2nd oversize
57.4x1 A 0.10 ÷ 0.30
Oil scraper ring
2nd oversize
57.4x2.5 A 0.10 ÷ 0.35
Compression ring
3rd oversize
57.6x1 A 0.15 ÷ 0.30
Oil scraper ring 3rd
oversize
57.6x1 A 0.10 ÷ 0.30
Oil scraper ring 3rd
oversize
57.6x2.5 A 0.10 ÷ 0.35
Maximum clearance after use: 1 mm
SEALING RINGS (150)
Name Description Dimensions Initials Quantity
Compression ring 62.6x1 A 0.15 ÷ 0.30
Oil scraper ring 62.6x1 A 0.20 ÷ 0.40
Oil scraper ring 62.6x2.5 A 0.20 ÷ 0.40
Compression ring
1st oversize
62.8x1 A 0.15 ÷ 0.30
Oil scraper ring 1st
oversize
62.8x1 A 0.20 ÷ 0.40
Oil scraper ring 1st
oversize
62.8x2.5 A 0.20 ÷ 0.40
Compression ring
2nd oversize
63.0 x 1 A 0.15 ÷ 0.30
Oil scraper ring
2nd oversize
63.0 x 1 A 0.20 ÷ 0.40
Oil scraper ring
2nd oversize
63.0 x 2.5 A 0.20 ÷ 0.40
Compression ring
3rd oversize
63.2 x 1 A 0.15 ÷ 0.30
Oil scraper ring 3rd
oversize
63.2 x 1 A 0.20 ÷ 0.40
Oil scraper ring 3rd
oversize
63.2 x 2.5 A 0.20 ÷ 0.40
Fly 125 - 150 4T Characteristics
CHAR - 17
