Back side
REAR INSTALLATION
Specification Desc./Quantity
1 Cable harness fairlead
2 Breather tube
3 Heater conductors and automatic choke pro-
tective sheath
4 Voltage regulator
5 HV coil
6 Earth node
7 Starter remote control
8 License plate light connector
Electrical system Fly 125 - 150 4T
ELE SYS - 58
