Battery recharge and starting
BATTERY CHARGER AND STARTING
Specification Desc./Quantity
1 Magneto flywheel
2 Voltage regulator
3 Pick - up
4 Main fusible 15A
5 Battery 12V-9Ah
6 Starter relay
7 Starter motor
8 Start up button
9 Front and rear brake light button
10 Brake light filament 12V-21W
11 Fuse 7.5 A
12 Key switch
13 electronic control unit
Fly 125 - 150 4T Electrical system
ELE SYS - 63
