Loctite 243 medium-strength threadlock
- Fit the freewheel on the magneto flywheel making
sure that the ground side is in contact with the fly-
wheel itself, i.e. with wheel seeger ring visible.
- Lock the six clamping screws in criss-cross fash-
ion to the prescribed torque.
Locking torques (N*m)
Screw fixing freewheel to flywheel 13 ÷ 15
- Oil the free wheel "rollers".
Refitting the intermediate gear
- Lubricate the gear housing on the engine crank-
case.
- Insert the intermediate gear with torque limiter
MP3 400 i.e. Engine
ENG - 45
