Swing-arm

SWINGING ARM

Code Action Duration

1 004058 Silent block - Replacement

2 003081 Swinging arm support flange

- replace

3 001072 Swinging arm - Engine-chas-

sis connection - Replacement

4 003080 Swinging arm on frame - Re-

placement

MP3 400 i.e. Time

TIME - 29
