This section is devoted to operations that can be carried out on the suspension.
Front
Removing the front wheel
- Remove the 5 fixing screws indicated in the pho-
tograph.
Locking torques (N*m)
Wheel fixing screw 20 ÷ 25
Front wheel hub overhaul
- Remove the ball bearing seeger ring indicated in
the photograph
Extract the ball bearing using the specific tool
Specific tooling
001467Y014 Pliers to extract ø 15-mm bearings
001467Y017 Bell for bearings, outside Ø 39 mm
Suspensions MP3 400 i.e.
SUSP - 2
