Top-case
Rear
Remove the four fixing screws of the cover and
release it from the two leverages.
Handles and top side fairings
- Operating from the rear case remove the two
screws indicated in the photograph.
- Remove the ceiling fitting indicated in the photo-
graph and remove the internal screw indicated in
the photograph.
- Remove the backrest cushion.
Chassis MP3 400 i.e.
CHAS - 14
