REAR BRAKE
Product Description Specifications
(°) Loctite 243 Medium strength threadlock Apply LOCTITE 243 medium-
strength threadlock
MUFFLER
Name Torque in Nm
Muffler heat guard fixing screw 4 ÷ 5
Screw for fixing muffler to the support arm 20 ÷ 25
Lambda probe clamp on exhaust manifold 40 ÷ 50
Exhaust manifold-muffler joint clamp 12 ÷ 13
Manifold - muffler diaphragm tightening clamp 16 ÷ 18
LUBRICATION
Name Torque in Nm
Oil pump cover screws 0.7 ÷ 0.9
Screws fixing oil pump to the crankcase 5 - 6
THERMAL UNIT AND TIMING SYSTEM
Name Torque in Nm
Spark plug 12 ÷ 14
Head fixing stud bolts: ***
Head fixing nuts 10 - 12
Exhaust / intake head fixing nuts: 10 - 12
Head lubrication control jet 5 - 7
coolant temperature sensor: 10 - 12
Lambda probe on exhaust manifold 10 - 12
injector fixing screw 3 ÷ 4
Counterweight screw 7 ÷ 8.5
Tensioner sliding block fixing screw: 10 - 14
Rpm timing sensor fixing screw: 3 - 4
Valve lifter mass stop bell fixing screws: 30 - 35
Inlet manifold screws 11 ÷ 13
Tappet cover fixing screws: 7 - 9
Throttle body fixing screws 11 ÷ 13
Head fixing screws 10 - 12
Camshaft retaining bracket screws: 4 ÷ 6
Tightener screw: 5 - 6
Tightener fastening screws: 11 ÷ 13
*** Apply a preliminary torque of 7 Nm in a crossed sequence. - Tighten by 90° in a crossed sequence. - Tighten again by 90° in
a crossed sequence.
TRANSMISSION COVER
Name Torque in Nm
Driven pulley nut 92 - 100
Drive pulley nut 160 - 175
Anti-vibration roller screw 16.7 - 19.6
M8 retainers for transmission cover 23 - 26
M6 retainer 11 ÷ 13
Anti-vibration roller retainer 17 - 19
Clutch ring nut 65 - 75
Air conveyor screws 11 ÷ 12
Water pump cover screws 3 ÷ 4
Characteristics MP3 400 i.e.
CHAR - 8
