Removal
- Remove the rear wheel.
- Loosen the nuts fixing the safety washers.
- Undo the two screws fixing the plate supporting
the calliper to the frame.
- Remove the calliper supporting clamp.
- Remove the brake disc
Refitting
- To fit the rear brake disc, follow the removal steps but in reverse order; be careful to tighten the screws
to the prescribed torque using threadlock.
Recommended products
Loctite 243 Medium strength threadlock
Loctite 243 medium-strength threadlock
Locking torques (N*m)
Rear disc screws 5 - 6.5 Nm
Braking system MP3 400 i.e.
BRAK SYS - 6
