PIAGGIO MP3 400 i.e. User Manual

- Unscrew the fixing nut.
- Remove the wheel hub.
- Unscrew the six bolts securing the disc to the
wheel hub.
- Remove the disc.
Refitting
- To fit the front brake disc, follow the removal steps but in reverse order; be careful to tighten the screws
to the prescribed torque using threadlock.
Recommended products
Loctite 243 Medium strength threadlock
Loctite 243 medium-strength threadlock
Locking torques (N*m)
Front disc screws 5 ÷ 6 Nm
Disc Inspection
Checking the disc is important; it must be perfectly clean, with no sign of rust, oil or grease or other dirt
and must not show signs of deep scoring.
Braking system MP3 400 i.e.
BRAK SYS - 8
