Flywheel cover

FLYWHEEL COVER

Code Action Duration

1 001087 Flywheel cover - replace

2 001113 Water pump - Replacement

3 001123 Oil filter -Replacement

4 001124 By-pass valve - Replacement

5 001057 Thermostat - Replacement

6 001062 Water pump command shaft -

Replacement

7 001150 Flywheel cover gasket - Re-

placement

8 001160 Minimum oil pressure sensor

- Replacement

9 007011 By-pass manifold - thermo-

stat - drain valve - Replace-

ment

10 001074 Oil vapour recovery pipe - Re-

placement

MP3 400 i.e. Time

TIME - 9
