Transmission cover

TRANSMISSION COVER

Code Action Duration

1 001065 Internal transmission cover -

Replacement

2 001096 External transmission cover -

Replacement

3 001131 Transmission air intake - Re-

placement

4 001135 Transmission cover bearing -

Replacement

5 001170 Air manifold - replacement

Time MP3 400 i.e.

TIME - 14
