Fuel tank
F
UEL
TANK
Code
Action
Duration
1
004137
Injector pump pipe - Replace-
ment
2
005010
Tank float - Replacement
3
004109
Fuel tank breather - Replace-
ment
4
004168
Fuel tank cap - Replacement
5
004138
Fuel reverse pipe - Replace-
ment
6
004005
Fuel tank - Replacement
7
004073
Fuel pump - Replacement
MP3 400 i.e.
Time
TIME - 25
368
370
