6.21
CLUTCHING
6
Clutch Assembly
1. Install moveable inner spring retainer if removed. Do not
apply oil or grease to the bearings.
2. Align the “X” marks on each of the sheaves during
reassembly.
3. Install spring into inner retainer.
4. Install outer retainer on top of spring.
5. Compress the outer retainer and install the snap ring.
Reassemble Sheaves
Snap Ring
