4.24
9926813 R04 - 2013-2016 RZR 570 Service Manual
© Copyright Polaris Industries Inc.
24. Test the fuel pump by turning on the key and
listening for the pump to activate. Cycle the key
several times to prime the system.
FUEL TANK REMOVAL
NOTE
Syphon as much fuel from the tank as possible before
attempting to remove it from the vehicle.
WARNING
Always wear safety goggles when working with high
pressure or flammable fluids. Failure to do so could
result in serious injury or complications.
1. Remove the driver and passenger seats along with
the rear service panel.
2. Disconnect the negative battery cable from the
battery located under the driver’s seat.
3. While holding a shop towel over the fuel line
connector, disconnect the quick connect fuel line
from the fuel pump. Move the fuel line out of the way
for tank removal.
NOTE
A small amount of fuel may come out of the fuel line or
tank. Properly drain fuel into a suitable container.
4. Disconnect the fuel pump electrical harness.
5. Remove the fuel tank vent hose clamp with a
suitable pliers and remove the vent line from the tank
vent fitting.
6. Remove the rear seat base assembly from the
vehicle by removing the two fasteners retaining the
rear seat base.
FUEL SYSTEM
