Page 103
P814 Miscellaneous Messages
This parameter determines whether notification messages are displayed on
the auxiliary line of the display in run mode when a miscellaneous relay is
switched on or off. The message is in the form “Clock ON”.
P816 Totaliser ( R )
This parameter determines whether or not the resettable totaliser will be
displayed in the auxiliary line of the display in run mode. When selected the
auxiliary display will scroll between the resettable totaliser and the totaliser
units selected. Default = 0 (Off).
When being used to totalise Flow the resettable totaliser can be reset whilst
in run mode via the “Totaliser” hot key by pressing “0” whilst Total (R)
is displayed.
Totaliser
P820 Totaliser
Displays the current value of the, non-resettable totaliser. During run mode
this totaliser can be viewed via the “Totaliser” hot key, . Unlike the
resettable totaliser this totaliser cannot be reset whilst in run mode, it can
however be reset whilst in program mode by accessing P820 Totaliser and
entering zero.
P821 Totaliser( R )
Displays the current value of the, resettable totaliser. This totaliser can be
allocated to appear, during run mode, on the auxiliary display line (P816)
or alternatively via the “Totaliser” hot key.
P822 Totaliser Decimal Places
This parameter determines the number of decimal places in the totaliser
during run mode. It can be set between 1 and 3. Default = 2
