Pulsar FlowCERT LITE User Manual

Page 45
Calculations
Rectangular Flume
ABSOLUTE
If the flow calculation is to be absolute P702 = 1 the flow will be calculated
using the formula: q = (2/3)
1.5
gn
0.5
C
s
C
v
C
d
bh
1.5
Where: q = flowrate
gn = gravitational acceleration (nominal value = 980.66 cm/s
2
)
C
s
= shape coefficient (value = 1)
C
v
= velocity coefficient calculated by FlowCERT LITE P721
C
d
= discharge coeffecient calculated by FlowCERT LITE P722
b = throat width P711
h = head
RATIOMETRIC
If the flow calculation is to be ratiometric P702 = 2 the flow will be
calculated using the formula: q= q
cal
(C
v
/C
vcal
)(C
d
/C
dcal
)(h/h
cal
)
1.5
Where: q = flowrate
q
cal
= flowrate at maximum head P705
C
v
= velocity coefficient calculated by FlowCERT LITE
C
vcal
= velocity coefficient at maximum head
C
d
= discharge coeffecient calculated by FlowCERT LITE
P722
C
dcal
= discharge coefficient at maximum head
h = head
h
cal
= maximum head P704
