Page 108
Allocation
P841 mA Allocation
By default the mA output will be representative of the reading obtained, as
determined by the Mode P100. This parameter is automatically set to the
correct default option when selecting the Mode P100 and Xducer (P101),
and under normal circumstances will not require changing.
The options, dependant on the value entered for Mode P100, are as follows:
mA output relates to Xducer 1 level.
Compensation Parameters
Offset
P851 Measurement Offset
The value of this parameter is added to the measured distance, in
Measurement Units (P104).
This Offset will be added to the level, as derived from the transducer, and
will affect everything including the reading on the display, the relay
setpoints and the mA output.
