Page 19
3) Auxiliary Display, scrolling twelve digit display.
Run Mode, displays measurement units (P104), status messages on
signal and transducer, detail of Hot Key function selected. It can be also
programmed to provide notification messages on alarms and pumps etc.
for full details please refer to Display Parameters in the relevant
parameter listing.
Program Mode, displays Menu and Sub Menu headings, parameter
details and options.
4) Communicator status enunciator displays the current status of remote
PC connection.
5) Bargraph, display, gives visual indication of measurement in % of span.
6) Level indicators
Run Mode, indicates in which direction the level is moving.
Program Mode, indicates at which level of the menu system you are at.
There are two main operating modes for your FlowCERT LITE, Run Mode
and Program Mode. There is also a Test Mode, used for checking the set-
up. All modes are now described.
Run Mode
This mode is used once the FlowCERT LITE has been set up in program
mode. It is also the default mode that the unit reverts to when it resumes
operation after a power failure.
When FlowCERT LITE is switched on for the first time, it will display, in
inches, the distance from the transducer face to the target. All relays by
default are switched off.
After programming is complete, any relays that are set will operate when the
level reaches the relevant setpoint, and the LED’s will change colour (unless
specifically switched off).
Program Mode
This mode is used to set up the FlowCERT LITE or change information
already set. You must use the built-in keypad (standard) or alternatively the
unit can be set up with a PC via the RS 232 Serial Interface (optional).
Entering a value for each of the parameters that are relevant to your
application provides all the programming information.
