Pulsar FlowCERT LITE User Manual

Page 52
To program the FlowCERT LITE for Example 3 BS3680 Weir by using the
Quick Setup menu, proceed as follows.
If required access the Program Mode
Key in the passcode 1997 and press ENTER
Using the ‘right’ arrow key go to the Quick Setup menu press ENTER and
as prompted, by the questions, select the relevant option and press ENTER.
Question
Option
PMD Type
3 = 3680 Weir
3680 Flumes
1 = Rectangular
Calculation
1 = Absolute
No. of Alarms
1 = 1 Alarm
Type Alarm 1
1 = High
Alarm No 1
3 = Set Relay 3
Xducer
1 = dB3
Volume Units
5 = US gallons
Time Units
2 = Per Minute
Measnt. Units
5 = inches
Empty Level
40.0 inches
Minimum Head
0.000 inches
Maximum Head
16.0 inches
Total Enable
1 = On
Totaliser ( R )
1 =Yes
Total Multiplier
7 = *1000
App. Width (Dim A)
18.0 inches
Crest Width (Dim B)
12.0 inches
Crest Height (Dim C)
10.0 inches
Programming is now complete and the unit can now be returned to the run
mode, press CANCEL until Run Mode? Is displayed on the LCD press
ENTER, and the FlowCERT LITE will return to Run Mode.
Note
If relay setpoints do not meet the exact requirements of the
application, they can be modified to suit by pressing ENTER when,
“For More Options Hit Enter”, is displayed, and entering new values
to relay setpoints as required. Alternatively the relevant relay
setpoint can be accessed either by the main menu system or directly
via parameter number and changed as necessary.
