Chapter 3 Setting Up the Autoloader
Connecting the Cables
LTO Ultrium 8-Slot Autoloader User’s Guide 21
2 Place one screw from the rack-mount kit into the hole in the front of
each bracket. If your rack has square mounting holes or the holes are
larger than the screws provided in the kit, use the clip-nuts to secure
the screws. Use a #2 PHILLIPS screwdriver to tighten the screws.
Figure 12 Securing
the Autoloader to the
Rack
Connecting the Cables 3
To connect the cables to the autoloader:
1 Make sure that the power switch on the front of the autoloader is off
(the right side of the power switch is pressed).
2 Connect the female end of the power cord to the AC outlet on the
back of the autoloader.
Note: The power cord shipped with the autoloader is a 120 VAC
three-conductor power cord for use in the United States
and Canada. An adapter for use outside of the United
States and Canada is also included.
P
O
W
E
R
M
E
N
U
-
+
S
E
L
E
C
T
