Chapter 4 Operating the Autoloader
Operator's Panel
LTO Ultrium 8-Slot Autoloader User’s Guide 27
• CLEAN DRIVE (Amber LED) — Lit when the drive is to be cleaned.
The LED will be turned off after the drive is cleaned successfully.
•
MEDIA ATTENTION (Amber LED) — Lit when there has been a failure
that indicates that there is a piece of media that is bad, marginal, or
invalid. It will be cleared when all invalid cartridges have been
exported from the autoloader.
•
ERROR (Red LED) — Lit when there is an unrecoverable autoloader
or drive failure. A message displays at the same time on the screen. It
will be cleared when the error state is resolved.
LCD 4 The LCD consists of two lines, with 16 characters per line. The screen
displays actions, status information, menu items, and error messages
equivalent to the operation mode.
Keypad 4 The keypad buttons are used for navigating the various menu options
that are available. For more information on the menu options, see Menu
Options on 28.
•
CANCEL button [X] — Push the Cancel button to cancel a user action
and return to the last menu item.
•
PREVIOUS button [-] — Navigate through menu items.
•
NEXT button [+] — Navigate through menu items.
•
ENTER button [ø] — Push the Enter button to go to a sub-menu or to
force a robotic action.
Note: The keypad buttons are only available for use in interaction
mode. For more information on operating modes, see
Operating Modes
on 30.
