Quantum QXS Series User Manual

Chapter 1: Components
QXS-3 Series Storage
QX and QXS Setup Guide 8
Figure11:12- and 24-Drive Expansion Chassis - Rear Panel Components
LINKLINK
SERVICE
IN OUT
LINKLINK
SERVICE
IN OUT
1 1
2
3
1. PowerSupplies(ACshown)
2. ExpansionI/OModuleA
3. ExpansionI/OModuleB
Figure12:Closeup of Expansion I/O Module
LINKLINK
SERVICE
IN OUT
1
2
3
4
1. DisabledButton(usedbyengineering/testonly)
2. ServicePort(usedbyservicepersonnelonly)
3. Mini-SASInPort
4. Mini-SASOutPort
