Quantum QXS Series User Manual

Chapter 1: Components
QXS-648 System
QX and QXS Setup Guide 30
Note:The 2U48 and 4U56 drive chassis support installation of hard-disk drives (HDDs) and solid-state
disks (SSDs). The drive chassis can have all HDDs or SSDs installed or a mixture of HDDs and SSDs.
QXS-648 System
The drive chassis include a bezel sub-assembly that attaches to the front panel of the chassis. The bezel,
comprised of a vented cover attached to an EMI shield, is pre-assembled and packed within a box contained
in the master shipping container. Instructions for attaching/removing the bezel are provided in the QX and
QXS Bezel Installation Guide.
2U48-Drive Chassis
The 2U48 drive chassis is used in QXS-648.
Figure37:2U Drive Chassis (Bezel Installed)
5
6
7
8
1
2
3
4
5
1. ChassisIDLED
2. ChassisStatusLED:UnitLocator
3. ChassisStatusLED:Fault/ServiceRequired
4. ChassisStatusLED:FRUOK
5. ChassisStatusLED:TemperatureFault
