Smart Module Series
SG368Z_Series_Hardware_Design 106 / 113
8.3.2. Plastic Reel
Figure 44: Plastic Reel Dimension Drawing
Table 56: Plastic Reel Dimension Table (Unit: mm)
8.3.3. Mounting Direction
Figure 45: Mounting Direction
øD1
øD2
W
380
180
72.5
