1 Introduction
This document describes the SG368Z series module’s features, performance, and air interfaces and
hardware interfaces connected to your applications. The document provides a quick insight into interface
specifications, RF performance, electrical and mechanical specifications, and other module information,
as well.
1.1. Special Marks
Table 1: Special Marks
For conciseness purposes, SG368Z-WF and SG368Z-AP will hereinafter be referred to collectively as
''the module'' in parts hereof applicable to both models, and individually as ''SG368Z-WF'' and
"SG368Z-AP" in parts hereof referring to the differences between them.
Unless otherwise specified, when an asterisk (*) is used after a function, feature, interface, pin
name, AT command, or argument, it indicates that the function, feature, interface, pin, AT
command, or argument is under development and currently not supported; and the asterisk (*)
after a model indicates that the sample of the model is currently unavailable.
Brackets ([…]) used after a pin enclosing a range of numbers indicate all pins of the same
type. For example, SDIO_DATA[0:3] refers to all four SDIO_DATA pins, SDIO_DATA0,
SDIO_DATA1, SDIO_DATA2 and SDIO_DATA3.
