Quectel SG368Z Series User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 13 / 113
2.2. Key Features
Table 4: Key Features
5180–5825 MHz
Bluetooth 4.2
2402–2480 MHz
-
Categories
Descriptions
Application Processor
⚫ Quad-core 64-bit ARM Cortex-A55 CPU
⚫ Up to 2 GHz
⚫ 32 KB L1 I-cache, 32 KB L1 D-cache, 512 KB L3 cache
GPU
ARM Mali G52 GPU
Memory
Industrial grade:
⚫ 8 GB eMMC + 1 GB LPDDR4X (default)
⚫ 16 GB eMMC + 2 GB LPDDR4X (optional)
Commercial grade:
⚫ 32 GB eMMC + 2 GB LPDDR4X (default)
⚫ 32 GB eMMC + 4 GB LPDDR4X (optional)
Operating System
Android 11*/12*/13, Linux (Kernel 4.19/5.10*)
Supply Voltage
⚫ 3.3–3.5 V
⚫ Typ.: 3.4 V
USB Interfaces
⚫ 1 × USB 3.0 and 2.0 OTG interface (USB0):
– Supports Host and Device modes
– Supports AT command communication, data transmission,
software debugging, firmware upgrade (only supports firmware upgrade
through USB 2.0)
– SS channel can be multiplexed into SATA0* interface
⚫ 1 × USB 3.0 and 2.0 Host interface (USB1):
– Only supports Host mode
– SS channel can be multiplexed into SATA1 or QSGMII/SGMII*
interface
⚫ 2 × USB 2.0 Host interfaces (USB2 and USB3):
– Only support Host mode
SD Card Interface
⚫ Complies with SD 3.0 protocol
⚫ 1.8/3.3 V SD card
⚫ SD card hot-plug
