Quectel SG368Z Series User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 93 / 113
6.3. Power Consumption
Table 44: SG368Z-WF Power Consumption
Modes
Conditions
Typ.
Units
OFF state
Power off
100
μA
Standby state
Screen off
5.5
mA
Wi-Fi 11a Tx
@ 6 Mbps
380
mA
@ 54 Mbps
370
mA
Wi-Fi 11b Tx
@ 1 Mbps
445
mA
@ 11 Mbps
380
mA
Wi-Fi 11g Tx
@ 6 Mbps
443
mA
@ 54 Mbps
369
mA
Wi-Fi 11n Tx
@ 7.2 Mbps 20 MHz
375
mA
@ 72.2 Mbps 20 MHz
355
mA
Wi-Fi 11n Tx
@ 15 Mbps 40 MHz
373
mA
@ 150 Mbps 40 MHz
364
mA
Wi-Fi 11ac Tx
@ 7.2 Mbps 20 MHz
395
mA
@ 86.7 Mbps 20 MHz
438
mA
@ 15 Mbps 40 MHz
391
mA
@ 200 Mbps 40 MHz
429
mA
@ 32.5 Mbps 80 MHz
392
mA
@ 433.3 Mbps 80 MHz
432
mA
Wi-Fi 11a Rx
@ 54 Mbps
TBD
mA
Wi-Fi 11b Rx
@ 11 Mbps
TBD
mA
Wi-Fi 11g Rx
@ 54 Mbps
TBD
mA
Wi-Fi 11n Rx
@ 200 Mbps 40 MHz
TBD
mA
