Quectel SG368Z Series User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 56 / 113
⚫ 1 group of RGB* interface: supports parallel 24 bits RGB output, with the maximum output resolution
up to 1920 × 1080 @ 60 fps
⚫ 1 group of BT1120* interface: supports 16 bits BT1120 output, with the maximum output resolution
up to 1920 × 1080 @ 60 fps
⚫ 1 group of BT656* interface: supports 8 bits BT656 output
4.10.1. eDP Interface
The module supports eDP V1.3 and supports 1 group of 4-lane eDP interface, with the maximum output
resolution up to 2560 × 1600 @ 60 fps.
⚫ Supports data rate: up to 2.7 Gbps/lane
⚫ Supports 1-lane or 2-lane or 4-lane mode
⚫ Supports AUX channel
⚫ Supports data rate up to 1 Mbps
Table 22: Pins Description of eDP Interface
Pin Name
Pin No.
I/O
Description
EDP_ML0_P
136
AO
eDP data 0 (+)
EDP_ML0_N
132
AO
eDP data 0 (-)
EDP_ML1_P
131
AO
eDP data 1 (+)
EDP_ML1_N
127
AO
eDP data 1 (-)
EDP_ML2_P
126
AO
eDP data 2 (+)
EDP_ML2_N
122
AO
eDP data 2 (-)
EDP_ML3_P
121
AO
eDP data 3 (+)
EDP_ML3_N
117
AO
eDP data 3 (-)
EDP_AUX_P
141
AIO
eDP auxiliary channel (+)
EDP_AUX_N
137
AIO
eDP auxiliary channel (-)
EDP_DET
70
DI
eDP hot-plug detect
