Quectel SG368Z Series User Manual

Smart Module Series
SG368Z_Series_Hardware_Design 94 / 113
Table 45: SG368Z-AP Power Consumption
⚫
6.4. Digital I/O Characteristics
Table 46: 1.8 V VCCIO I/O Characteristics (Unit: V)
Wi-Fi 11ac Rx
@ 433.3 Mbps 80 MHz
TBD
mA
Bluetooth Tx Channel 0
-
322
mA
Bluetooth Tx Channel 38
-
324
mA
Bluetooth Tx Channel 78
-
326
mA
Bluetooth Rx Channel 38
-
TBD
mA
Modes
Conditions
Typ.
Units
OFF state
Power off
100
μA
Standby state
Screen off
5.5
mA
The power consumption data above is for reference only, which may vary among different modules. For
detailed information, contact Quectel Technical Support for the power consumption test report of the
specific module.
Parameters
Descriptions
Min.
Max.
V
IH
High-level input voltage
0.65 × VCCIO
VCCIO + 0.3
V
IL
Low-level input voltage
-0.3
0.35 × VCCIO
V
OH
High-level output voltage
1.4
VCCIO + 0.3
V
OL
Low-level output voltage
-0.3
0.4
NOTE
