Radwin 1000 User Manual

Ethernet Interface Appendix A
RADWIN 1000/2000/5000 User ManualVersion 2.5.30p3 A-4
* Relevant for RADWIN 1000 RW-1020-0150 / RADWIN 2000 RW-2020-
0150 models only
Ethernet Interface
Channel Bandwidth
5, 10, and 20 MHz, (10MHz not supported in the 5.8 GHz
band)
Radio Modulation 2x2 MIMO-OFDM (BPSK/QPSK/16QAM/64QAM)
Adaptive Modulation & Coding Supported
Automatic Channel Selection Supported
Radio Regulation
FCC 47 CFR Part 15 Subpart C, E, Part 90 Subpart Y, Z
IC (Canada) RSS-210, RSS-111, RSS-192, RSS-197
Duplex Technology TDD
Error Correction FEC k = 1/2, 2/3, 3/4, 5/6
Rate – Single Antenna [Mbps] 6.5 13 19.5 26 39 52 58.5 65
Rate – Single Antenna in the
5.8 GHz spectrum band
[Mbps]
13.5 27 40.5 54 81 108 121.5 135
Rate – Dual Antenna [Mbps] 13 26 39 52 78 104 117 130
Rate –Dual Antenna in the 5.8
GHz spectrum band [Mbps]
27 54 81 108 162 216 243 270
Modulation
BPSK QPSK 16QAM 64QAM
FEC [k=] 1/2 1/2 3/4 1/2 3/4 2/3 3/4 5/6
Max Tx Power [dBm]
25
24 21 19
18
Sensitivity (dBm) @BER <10e-
11 (20MHz)
-88 -86 -83 -81 -80 -72 -70 -67
Encryption AES 128
Throughput
Up to 270Mbps in the 5.3/5.4 IC and 5.8 GHz spectrum
bands
Number of Ethernet ports IDU-C and E: 2; PoE Device: 1
Type 10/100BaseT with Auto-Negotiation (IEEE 802.3u)
Framing/Coding IEEE 802.3
Line Impedance 100 Ω
VLAN Support Transparent
Connector RJ-45
Maximum Frame Size 2048 Bytes
Bridge
Layer 2, self-learning of up to 2047 MAC addresses (IEEE
802.1Q), hub/Bridge selectable mode
Latency 3 msec (typical)
