Radwin 1000 User Manual

The Indoor Units (IDU) Chapter 1
RADWIN 1000/2000/5000 User ManualVersion 2.5.30p3 1-8
The ODU products available in release 2.5.30p3 are shown below:
The only available external antenna is, single bipolar.
For further information, see page 4-20, Installing the Link: Step 4, Tx
Power and Antenna Settings.
The Indoor Units (IDU)
IDU-C
The IDU-C has the service ports and provides aggregation of these services
towards the ODU that transports them over the air. The IDU-C also provides
power to the ODU.
The IDU-C is a carrier-class 19 inch, 1U unit, providing two Ethernet ports,
dry contact alarms and indication LEDs. It has two DC power feed connec-
tors. An AC to DC converter is available for powering the IDU-C from an AC
source. The IDU-C is designed to be rack mounted.
One IDU-C product is available in release 2.5.30p3:
Table 1-1: Available ODU Products - Release 2.5.30p3
Part Number
Description
Form Factor Frequency Bands and Regulations
RW-2050-0150
RW-5550-0150
Integrated antenna
FCC/IC5.725 – 5.850 GHz
FCC/IC5.250 – 5.350 GHz
FCC/IC5.470 – 5.725 GHz
FCC/IC4.940 – 4.990 GHz
FCC/IC2.400 – 2.4835 GHz
RW-2050-0250
Connectorized for exter-
nal antenna (2x N-type)
RW-2020-0150
RW-1020-0150
Integrated and connector-
ized antenna (2x N-Type)
FCC/IC2.400 – 2.4835GHz
RW-1030 3 GHz BAND
RW-2030 3 GHz BAND
RW-2030 3 GHz BAND
FCC/IC3.650 – 3.700GHz
IC3.475 – 3.650GHz
RW-5200-0250
RW-5550-0250
Connectorized for exter-
nal antenna (2 x N-type)
FCC/IC5.725 – 5.850 GHz
FCC/IC5.250 – 5.350 GHz
FCC/IC5.470 – 5.725 GHz
FCC/IC 5.725 – 5.825 GHz
FCC/IC4.940 – 4.990 GHz
Table 1-2: Release 2.1 IDU-C Products
Part Number
Ethernet
ports
Power
Form
factor
7200-2000 2
Dual DC feed
-20 to -60VDC
19" 1U
