Radwin 1000 User Manual

RADWIN 1000/2000/5000 User ManualVersion 2.5.30p3 iv
Indoor Units comply with part 15 of the FCC rules and ICES-003 standard. Operation is
subject to the following two conditions:
(1) These devices may not cause harmful interference.
(2) These devices must accept any interference received, including interference that may
cause undesired operation.
Canadian Emission Requirements for Indoor Units
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numẻrique de la classe B est conforme ả la norme NMB-003 du Canada.
Safety Practices
Applicable requirements of National Electrical Code (NEC), NFPA 70; and the National
Electrical Safety Code, ANSI/IEEE C2, must be considered during installation.
NOTES:
1. A Primary Protector is not required to protect the exposed wiring as long as the exposed
wiring length is limited to less than or equal to 140 feet, and instructions are provided to
avoid exposure of wiring to accidental contact with lightning and power conductors in
accordance with NEC Sections 725-54 (c) and 800-30.
In all other cases, an appropriate Listed Primary Protector must be provided. Refer to Articles
800 and 810 of the NEC for details.
2. For protection of ODU against direct lightning strikes, appropriate requirements of NFPA
780 should be considered in addition to NEC.
3. For Canada, appropriate requirements of Section 60 of the CEC 22.1should be considered
as applicable.
4. E1/T1 ports are intended for connection to indoor lines only and are not exposed to
outdoor plants.
Warning
The antenna used for this transmitter must be installed to provide a
separation distance of at least 225cm from all persons and must not be co-
located or operated in conjunction with any other antenna or transmitter.
Warning
This product was tested with special accessories - indoor unit (IDU or
PoE), FTP Cat 5e shielded cable with sealing gasket, 12 AWG grounding
cable - which must be used with the unit to insure compliance.

Radwin 1000 Specifications

General

Brand	Radwin
Model	1000
Category	Microphone system
Language	English

Summary

Introduction to RADWIN 1000/2000/5000

Key Applications

Key Features of RADWIN 1000/2000/5000

Highlights high capacity, spectral efficiency, advanced air interface, high Tx power, range, and ease of use.

Site Preparation for Wireless Links

Planning the Link Site

Outlines the process of link site planning, including surveys and necessary equipment.

The Site Survey Process

Hardware Installation Procedures

Safety Practices and Grounding

Covers RF energy exposure prevention, proper grounding, and lightning protection guidelines.

Installation Sequence and Connections

Details the hardware installation steps, outdoor/indoor connections, and ODU/antenna alignment.

Link Installation using RADWIN Manager

RADWIN Manager Installation and Setup

Link Installation Wizard Overview

Explains the seven steps of the Link Installation Wizard, from welcome to summary.

Configuring the Wireless Link

Link Configuration Wizard Steps

Details the six steps of the Link Configuration Wizard, covering system, channel, Tx power, and services.

Site Configuration Settings

Editing Site Configuration Parameters

Explains how to edit site-specific parameters via dialog panels and menus.

Network, Time, and Security Settings

Monitoring and Diagnostics

Retrieving Link Information (Get Diagnostics)

Explains how to collect and save link and system diagnostics data for troubleshooting.

Link Compatibility and Reinstallation

Performance Monitoring and Logs

Covers monitoring traffic, collecting statistics, and managing Monitor/Events logs.

RADWIN Manager Traps and Events Log

Troubleshooting and System Maintenance

Provides guidance on troubleshooting LED faults, replacing ODUs, and restoring factory setup.

Appendix D: Link Budget Calculator

Link Budget Calculator Calculations

Running the Link Budget Calculator

Guides on how to access and use the Link Budget Calculator from the CD or RADWIN Manager.

Appendix E: Lightning Protection and Grounding

Grounding for Antenna Cable

Grounding for Indoor/Outdoor Units

Details ODU and IDU grounding procedures using appropriate wires and connection points.

External Lightning Surge Suppressors

Covers the installation of surge arrestor units and grounding for protection against lightning.

Appendix H: Combo Configuration Tool

Using the Combo Configuration Tool

Provides step-by-step instructions for operating the tool and configuring frequency bands.
