Raymarine eS Series User Manual

12.1eSSeriessparesandaccessories
Spares
Partnumbers
ItemeS7xeS9xeS12x
Trunnion
(bracket)
mountkit
R70381R70384R70389
Bezel
piecesand
Home/Menu
buttonkit
R70379R70383R70387
Suncover
R70378R70382R70386
Powercable
–Straight
1.5m(4.9ft)
R70159
N/AN/A
Powerand
datacable
–Straight
1.5m(4.9ft)
N/A
R62379R62379
Flushmount
sealkit
R70380R70385R70388
Accessories
Partnumbers
ItemeS7xeS9xeS12x
Video/NMEA
0183cable
R70414
N/AN/A
Rear
mounting
bracket
A80341A80342A80343
Powercable
–Angled
1.5m(4.9ft)
A80221
N/AN/Aangled
powercable
Powerand
datacable–
Angled1.5m
(4.9ft)
N/A
R70029R70029
RMK-9
MFDremote
network
keypad
A80217
RCU-3
Bluetooth
remote
control
E62351
12.2DigitalClearPulseTransducers
andaccessories
Thetransducerslistedbelowcanbeconnected
directlytosonarvariantMFDs.
Depthtransducers
PartnumberImageMountingHousing
A80170 In-HullP79
DepthandTemperaturetransducers
PartnumberImageMountingHousing
A80150 TransomP48
A102140 TransomP48
(widebeam)
E66073
In-hull/
Trolling
P74
A80171 Thru-hull—
Lowprole
P319
E66087 Thru-hull
B60(20°
angle)
E66088 Thru-hull
B60(12°
angle)
A80172 Thru-hullB258
A80173 Thru-hull—
Lowprole
B164
A80214 Thru-hull
SS60(600W,
0°angle)
130eSSeriesinstallationinstructions
