Raymarine eS Series User Manual

Transducerconnection—MinnKotatransducer
D12259-2
4
2
3
1
1.600WsonarvariantMFD
2.MinnKotatransduceradaptorcable(A62363)
3.MinnKotatransducercable
4.MinnKotatransducer
Forfurtherinformationregardingsonarmodule
installation(includingpowerconnectionand
mounting),refertotheinstallationinstructions
suppliedwiththesonarmodule.
Sonarvariantmultifunctiondisplays
600Wsonarvariants
CHIRPDownVision
TM
variants
a67a68
a77
a78
a97a98
a127a128
c97
eS78
c127
eS98
e7D
eS128
e97
e127
eS77
eS97
eS127
Importantsoftwarerequirementsformultiple
sonarsystems
Ifyoursystemincludesmorethanonesourceof
sonardatayoumustensurethatanyCP300or
CP450Csonarmodulesarerunningsoftwareversion
v4.04orlater.
Thisappliestosystemswhichinclude:
•AnynumberofMFD(s)withaninternalsonar
moduleplusaCP300and/orCP450Csonar
module;or
•NoMFD(s)withaninternalsonarmodule,but
morethanoneCP300orCP450Csonarmodule.
ThisdoesNOTapplytoanysystemsthatdoNOT
includeaCP300orCP450Csonarmodule.
Note:Forsoftwaredownloadsandinstructions
onhowtoupdatethesoftwareforyourproduct(s),
visitwww.raymarine.com/software.
4.10Radarnetworkconnection
RadarunitsareconnectedtotheSeaTalk
hs
network,
usuallyviaaRaymarine
®
networkswitch.On
smallersystemstheRadarmaybeconnected
directlytothedisplay’snetworkconnection.
Radarconnectedvianetworkswitch
D12252-3
4
2
1
5
6
3
1.Radarscanner
2.Raymarine
®
networkswitch
3.MFD
4.RayNetRadarcable
5.VCM(VoltageConverterModule)—(required
forOpenArrays)
6.Powerconnection
Radarconnecteddirectlytothedisplay
D12253-3
4
1
2
3
1.Radarscanner
Cablesandconnections
41
