4.17HDMIvideooutput
IfyourMFDhasaHDMIoutputconnectionthe
MFD’sscreencanbeoutputtoanexternaldisplay.
RefertotheConnectionOverviewsectionto
establishifyourMFDhasaHDMIoutput.
D12916-2
3
2
1
1.MFD
2.Externaldisplay(Seenotebelow)
3.Raymarine5m(16.4ft)HDMIvideooutputcable
(A80219)
Note:
1.Theexternaldisplayyouareconnectingto
mustsupportthe720pstandardtoenableyou
toviewthemultifunctiondisplayscreenonthe
externaldisplay.Themultifunctiondisplay’s
videooutputresolutionisxedat720p.
2.TheHDMIcablemustonlybeconnectedtoan
externaldisplaythatiselectricallyisolatedfrom
thevessel’sdcpowersupply(i.ethescreen
andthe0Voftheexternaldisplay’sHDMI
connectormustnothaveadirectconnection
tothevessel’sdcpowersupply).
ForfurtherassistancepleasecontactRaymarine
technicalsupport.
4.18Videoconnection—composite
AnalogcamerascanbeconnecteddirectlytoMFDs
thathaveacompositevideoinputconnection.
RefertotheConnectionOverviewsectionto
establishifyourMFDhasacompositevideoinput.
MFDsthatdonothaveacompositevideoinput
connectioncanonlybeconnectedtoIPcameras.
D12178-3
3
4
2
1
1.MFD
2.ConnectiontoMFD(Power/NMEA/Videocable)
3.BNCvideoconnector
4.Camera(videosource)
Examplesofothervideosourcesthatyoucan
connecttothevideoinputconnection:
•Thermalcamera
•DVDplayer
•Portablemediaplayer
Note:Tolistentoaudio,anyconnectedplayerwill
requireexternalspeakerstobeconnectedtothe
player’saudiooutput.
Videospecication
SignaltypeComposite
Format
PALorNTSC
ConnectortypeBNC(female)
Outputresolution
720p
Cablesandconnections
47
