Raymarine eS Series User Manual

4.9Sonarmoduleandtransducer
connection
Externalsonarmodulescanbeconnecteddirectlyto
thedisplay’snetworkconnectionorcanbeconnected
totheSeaTalk
hs
network,viaaRaymarine
®
network
switch.
2connectionsarerequired:
•Networkconnection—transmitsthesonardata
toacompatibleRaymarine
®
MFD.
•Transducerconnection—Internalandexternal
sonarmodulesrequireconnectiontoacompatible
transducer.Internal600WandinternalCHIRP
DownVision
TM
sonarvariantdisplaysfeaturea
built-inmodule,enablingacompatibletransducer
tobeconnecteddirectlytothedisplay.
Networkconnection
Multiplesonarmodulescanbeconnectedtothe
samenetwork.
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
D12975-2
2
4
3
5
3
3
1
1.MFD
2.Raymarine
®
networkswitch
3.RayNetnetworkcables
4.Sonarmodule1(e.g.CHIRPsonarmodule)
5.Sonarmodule2(e.g.CHIRPDownVision
TM
sonarmodule)
Transducerconnection—Internal600WMFD
directconnection
2
D12256-2
1
3
1.600WsonarvariantMFD
2.600WMFDtransducer
Referto12.2DigitalClearPulseTransducersand
accessoriesforalistoftransducerthatcanbe
connecteddirectlyto600Winternalsonarvariant
MFDs.
Transducerconnection–Internal600WMFD
connectionviaoptionaladaptorcable
Anoptionaladaptorcableisavailabletoallow
connectionofexternalsonarmoduletransducersto
internal600WvariantMFDs.
D12257-2
2
3
1
1.600WsonarvariantMFD
2.Adaptorcable(E66066)
3.600Wexternalsonarmoduletransducer.
Transducerconnection—CHIRPDownVision
TM
MFDdirectconnection
D13334-1
2
1
1.CHIRPDownVision
TM
sonarvariantMFD
2.CHIRPDownVision
TM
Transducer
Referto12.3DownVision
TM
transducersand
accessoriesforalistoftransducerthatcanbe
connecteddirectlytoCHIRPDownVision
TM
sonar
variantMFDs.
Note:TheCPT200SideVision
TM
transducer
cannotbeconnecteddirectlytoaDownVsion
TM
variantMFD.
40eSSeriesinstallationinstructions
