Raymarine eS Series User Manual

PartnumberImageMountingHousing
A80215 Thru-hull
SS60(600W,
12°angle)
A80216 Thru-hull
SS60(600W,
20°angle)
Depth,SpeedandTemperature(DST)transducers
PartnumberImageMountingHousing
A66090 Thru-hullB744V
(including
fairingblock)
A102138 TransomP58
Accessories
PartnumberItemNotes
A62363
1m(3.28ft)Minn
Kotatransducer
adaptorcable
Onlyfordirect
connectiontosonar
variantmultifunction
display.
E66066
0.5m(1.64ft)
transduceradaptor
cableforDSM
transducers
Forconnectingany
600wattsonar
module-compatible
sonartransducer
directlytoasonar
variantmultifunction
display.
E66074
3m(9.84ft.)
transducerextension
cable
12.3DownVision
TM
transducersand
accessories
Thetransducerslistedbelowcanbeconnected
directlytoDownVision
TM
variantMFDs.
Depthandtemperaturetransducers
PartnumberImageMountingHousing
A80270 Transom
CPT-100
plastic
A80277 Thru-hull
CPT-110
plastic
A80271 Thru-hull
CPT-120
bronze
PartnumberDescriptionNotes
A80207Transomtransducer
shieldforvesselswith
atrollingmotor
A80273
4m(13.12ft)
transducerextension
cableforCPT-100,
CPT-110and
CPT-120transducers
Sparesandaccessories
131
