4.13AISconnection
AcompatibleAISunitcanbeconnectedusing
SeaTalk
ng®
orNMEA0183.
ConnectionusingSeaTalk
ng®
D12263-2
SeaTalk
ng
1
3
2
1.MFD
2.SeaTalk
ng®
connectiontoMFD.
3.SeaTalk
ng®
AISreceiver/transceiver.
AnAISunitcanbeconnectedtotheMFDby
followingthedetailsprovidedinsection4.8NMEA
0183connection—Power/NMEA/Videocableand
theinstallationinstructionsprovidedwiththeunit.
4.14Fastheadingconnection
IfyouwishtouseMARPA(radartargetacquisition)
functionsonyourmultifunctiondisplayyouneed
either:
•Anautopilotconnectedtothemultifunctiondisplay
viaSeaTalk
ng
orNMEA0183.Thecompassis
connectedtothecoursecomputerandcalibrated
viathepilotcontrolhead;or:
•ARaymarineorthird-partyfastheadingsensor
connectedtothemultifunctiondisplayviaNMEA
0183.
Note:PleasecontactyourdealerorRaymarine
technicalsupportformoreinformation.
Cablesandconnections45
